ReactFlow Prototype
Advanced ReactFlow implementation featuring custom nodes, edges, and complex grouping.
Executive Summary
Simplifying complex business logic and architectural mapping through a visual, node-based interface.
This project showcases advanced flow-based UI capabilities, including custom logic for nodes and edges, sophisticated element grouping, and robust connection validation to ensure a seamless user experience.
Core Infrastructure
Custom Nodes
Advanced styling and logic for specialized node types.
Custom Edges
Dynamic, interactive, and visually appealing connection behaviors.
Complex Grouping
Logical organization of nodes and edges into manageable units for large-scale flows.
Connection Validation
Built-in rules to prevent invalid states, such as prohibiting self-connections.
Design Philosophy
Built as a research prototype to explore the limits of node-based interfaces for complex business logic orchestration and spatial data visualization.
Realizing that visual nodes could represent complex backend microservices, turning architectural mapping into an interactive, spatial experience with robust connection validation.
Technical Architecture
Managing deeply nested state and real-time pathfinding logic for dynamic edges and complex element grouping without sacrificing canvas performance.
Engineered With
- React
- @xyflow/react (ReactFlow)
- Tailwind CSS
- Framer Motion
Performance Goal
- Smooth canvas performance with 100+ nodes
- Optimized state management for complex logic
- Fast edge pathfinding calculations
System Integrity
- Robust connection validation logic
- Secure export/import of workflow data
- Strict node relationship validation
